For an AppExchange app, the integration method you pick has to clear two bars: it has to work within Salesforce's callout governor limits, and it has to pass the security review.

Use Named Credentials for authenticated callouts so secrets are never hardcoded, declare every endpoint, and store any partner secrets in protected custom metadata. Below is each method and the limits and review rules that decide it.

Most integration guides are written for one-off org work. A managed package is different: your code runs in someone else's org, so credential handling and endpoint declaration aren't optional — they're what the review checks.

Named Credentials (split into Named Credential + External Credential since Winter '23) let Salesforce manage the OAuth token lifecycle and encrypt secrets, and you reference them in Apex as callout:My_Named_Credential/path. External Services turns an OpenAPI 2.0 or 3.0 schema into invocable actions usable in Flow with no Apex. External Objects (OData 2.0/4.0/4.01) surface external data as __x objects without copying it into the org.

These are hard platform limits, verified in the Apex Developer Guide (Salesforce):

The one that bites in production: you can't make a callout after an uncommitted DML in the same transaction. Make callouts first, or move them into a @future(callout=true) method, a Queueable, or a Batch job.

This is where managed packages fail, and where generic integration guides go silent. The review specifically looks at:

• Secret storage. Hardcoded secrets are an automatic fail. Approved storage: Protected Custom Metadata (for partner-owned secrets), Protected Custom Settings (for subscriber-owned secrets), Named/External Credentials, or an encrypted custom object with the key held in protected metadata.

• Endpoint declaration. Every outbound host must be declared — Remote Site Settings for unauthenticated calls, Named Credentials for authenticated ones. Undeclared callouts are blocked at runtime and flagged.

• Transport security. HTTPS required; protocol security must stay on.

• Data handling. CRUD and field-level security enforced on data you read or write, and no secrets or stack traces in logs.

Salesforce runs this with static analysis (Checkmarx, Code Analyzer/PMD), dynamic scanning (OWASP ZAP, Burp), and manual review.

Up to 100 callouts per transaction.

The default is 10 seconds. You can set it per callout from 1 ms up to 120,000 ms (120 seconds), and the cumulative timeout per transaction is capped at 120 seconds.

Salesforce blocks callouts when there's uncommitted DML in the same transaction. Make the callout before any DML, or move it into an async context (@future(callout=true), Queueable, or Batch).

Named Credentials for authenticated endpoints — Salesforce manages the token and encrypts the secret. Remote Site Settings cover unauthenticated hosts. Named Credentials also remove the need for a separate Remote Site Setting for that host.

Never hardcoded. Use Protected Custom Metadata (partner-owned secrets), Protected Custom Settings (subscriber-owned), Named/External Credentials, or an encrypted custom object with the key in protected metadata.

Apex callouts give full programmatic control. External Services generates low-code Flow actions from an OpenAPI schema. External Objects surface large external datasets as records without copying data into Salesforce.

Yes — for the host covered by the Named Credential, you don't need a separate Remote Site Setting.

Use Named Credentials with External Credentials so Salesforce stores and refreshes the token. For partner-owned API keys, use Protected Custom Metadata.

In a Salesforce AppExchange (managed package) app, choose the integration method by use case: Apex callouts for custom logic, Named Credentials for authenticated OAuth callouts (the preferred pattern), External Services for low-code Flow actions, External Objects for large read-heavy datasets, and Platform Events for async. Apex allows 100 callouts per transaction, a 10-second default timeout (max 120 seconds), and no callout after pending DML. The security review fails hardcoded secrets — store them in Protected Custom Metadata, Protected Custom Settings, or Named Credentials — and requires every endpoint declared via Remote Site Settings or Named Credentials.
